EN10204 3.1 Stainless Steel Seamless Tube ASTM A213 TP304/304L 1'' X 0.083'' X 20FT

Spezilla is a leading manufacturer and exporter of seamless stainless steel tubes, we have been exporting our tubes to more than 20 coutries since 2008. We are ISO9001:2008 certified manufacturer with very strcit quality control procedures. Spezilla is a good choice for your seamless stainless steel requirements.

Spezilla supplies seamless stainless steel tube per ASTM A 213, ASTM A 269 and ASTM A 511. We supply common grades of stainless steel such as 304, 304L, 316, and 316L in standard tube sizes and wall thicknesses, as well as less common austenitic stainless steel tubing in 304H, 309S, 310S, 317L, 321H, 347H. Most sizes of seamless stainless steel tube can be cut to exact sizes. Non standard sizes can be made to order. Contact our team today and tell us your exact seamless stainless steel tubie requirement.

Outside Diameter: 6.00 mm to 38.1mm

Wall Thickness: 0.50 mm to 3.00 mm

Grades: TP 304/L/H, TP 316/L/H/Ti, TP 310/H/L/S, TP 317/L, TP 321/H, TP 347/H, TP 405, TP 409, TP 410, TP 430, UNS S 31500, 31803, 32205, 32750, 32760

Description:

Available Tube Product Forms:

Straight.

Coiled.

Typical Applications:

Seamless bright annealed stainless steel tubing is used for many applications that require resistance to high pressures, high temperatures, and corrosive environments. These include, but are not limited to: petrochemical, gas, nuclear, food and beverage, and chemical plants. Various wall thicknesses are available to suit a range of pressure requirements, and several different finishes are available to achieve the desired aesthetic.

Quality Assurance:

Spezilla's seamless stainless steel tubes are produced acc. to the following process and inspection to assure our quality:

1. Chemical Composition Analysis Test With 100% PMI.

2. Solution Annealing / Bright Annealed.

3. 100% Hydrostatic Test and 100% Eddy Current Test

4. Mechanical Tests includes Tension Test, Flattening Test, Flaring Test, Hardness Test.

5. Impact Test subject to Standard request.

6. Grain Size Test and Intergranular Corrosion Test.

7. Visual Test and Endoscope Test for Surface Quality Test

Typical Manufacturing Specifications:

ASTM A213

ASTM A269

ASTM A270

EN10216-5

Also individual customer specifications.

Spezilla specialise in manufacturing high quality precision stainless steel tube and other corrosion resistant alloy tubes that are designed to industry and customer specifications. Our products are manufactured to the highest quality standards and are very competitively priced. Our mission is to provide customized, flawless, reliable, and affordable corrosion resistant steel tubes to the world.

Tube Type:            Welded, Welded & Drawn. Straight Length or Coils.

Tube Materials:      Austenitic:    304, 304L, 316L, 321, 316Ti, 317L, 904L, 254 SMO;

                                                   1.4301, 1.4307, 1.4401, 1.4404, 1.4541, 1.4571, 1.4539, 1.4547;

                              Duplex:         2205, 2507;  1.4462, 1.4410;

                              Ferritic:         409, 439, 441, 444; 1.4512, 1.4510, 1.4509, 1.4521;

                              Nickel Alloy:  800, 800H, 800HT, 825, C276; 1.4876, 1.4958, 1.4959, 2.4858, 2.4819;

                              Titanium:       Gr.1, Gr.2;

Tube Size:              O.D. 4.00 - 38.10MM, W.T. 0.30 - 3.0MM.

Tube Finish:           As Welded, Bright Annealed, Annealed & Pickled, Polished, Custom Cutting.

Tube Standards:    ASTM A249, A268, A269, A270, A688, A789, B338;

                               EN 10217-7 TC1 & TC2, EN 10296-2, EN10357 etc.

Applications:          Heat Exchangers, Food & Beverage, Heating Elements, Automative, Tube Manipulation etc.

Spezilla appreciates the opportunity to help you with your questions about our operations, our products, our services or any other aspect of our business. We understand the demands of placing orders and the need for fast quotes, so we guarantee a response in 24 hours or less.
