1.4301 Polished Stainless Steel Welded Tubes DIN 11850 Grade 85 X 2.0MM

    Buy cheap 1.4301 Polished Stainless Steel Welded Tubes DIN 11850 Grade 85 X 2.0MM from wholesalers

    Buy cheap 1.4301 Polished Stainless Steel Welded Tubes DIN 11850 Grade 85 X 2.0MM from wholesalers
    • Buy cheap 1.4301 Polished Stainless Steel Welded Tubes DIN 11850 Grade 85 X 2.0MM from wholesalers
    • Buy cheap 1.4301 Polished Stainless Steel Welded Tubes DIN 11850 Grade 85 X 2.0MM from wholesalers
    • Buy cheap 1.4301 Polished Stainless Steel Welded Tubes DIN 11850 Grade 85 X 2.0MM from wholesalers
    • Buy cheap 1.4301 Polished Stainless Steel Welded Tubes DIN 11850 Grade 85 X 2.0MM from wholesalers

    1.4301 Polished Stainless Steel Welded Tubes DIN 11850 Grade 85 X 2.0MM

    Ask Lasest Price
    Brand Name : SPEZILLA
    Model Number : WLD
    Certification : ISO9001, TS16949, PED, AD2000
    Price : NEGOCIATION
    Payment Terms : T/T, L/C
    Supply Ability : 100TONS/MONTH
    Delivery Time : Ex-Mill 15 - 30DAYS
    • Product Details
    • Company Profile

    1.4301 Polished Stainless Steel Welded Tubes DIN 11850 Grade 85 X 2.0MM

    DIN 11850 Grade 1.4301 85 X 2.0MM Welded Stainless Steel Tube OD 240G. Polished.


    DIN EN 1.4301 material (steel name is X5CrNi18-10) is a universal austenitic stainless steel with good resistance to atmospheric, organic and inorganic chemicals. It is widely used due to its excellent intergranular corrosion resistance, good cold deformability, good deep drawability and weldability.


    DIN EN 1.4301 stainless steel has good atmospheric corrosion resistance up to 300 °C, and good resistance to many (lightly corrosive) organic and inorganic chemicals. It can also be used at very low temperatures, but there are some limitations in marine, coastal and chloride-containing solutions.


    EN X5CrNi18-10 is non-magnetic in the annealed state, but it may become slightly magnetic due to the addition of martensite or ferrite during cold working or welding.


    Description:


    Item Code:SPW-1.4301
    Tube OD.:85MM
    Wall:2.0MM
    Length:6000MM
    Material:1.4301
    Standard:EN10217-7, DIN 11850
    Finish:BA / Bright Annealed. OD Polished
    Type:Welded
    Certification:ISO9001:2015
    Mill Test Certificate:EN10204 3.1
    Packing:Sleeved, Wooden Boxed

    Chemical Composition 1.4301 Welded Stainless Steel Tube:


    Chemical Element% ( Weight )
    Carbon (C)0.0 - 0.08
    Chromium (Cr)17.500 - 19.50
    Manganese (Mn)0.0 - 2.00
    Silicon (Si)0.0 - 1.00
    Phosphorous (P)0.0 - 0.05
    Sulphur (S)0.0 - 0.03
    Nickel (Ni)8.00 - 10.50
    Nitrogen (N)0.0 - 0.11
    Iron (Fe)Balance

    Mechanical Property 1.4301 Welded Stainless Steel Tube:


    Mechanical PropertyValue
    Proof Stress190 Min MPa
    Tensile Strength500 to 700 MPa
    Elongation A50 mm45 Min %
    Hardness Brinell215 Max HB


    Available Tube Product Forms:

    Straight.


    Typical Applications:

    Due to its good corrosion resistance, processability and weldability, EN 1.4301 stainless steel is widely used in chemical, tableware, watches, auto parts, medical equipment, architectural decoration, aerospace and electrical appliances.


    Quality Assurance:

    Spezilla's 1.4301 welded stainless steel tubes are produced acc. to the following process and inspection to assure our quality:

    1. Chemical Composition Analysis Test With 100% PMI.

    2. Solution Annealing / Bright Annealed.

    3. 100% Hydrostatic Test and 100% Eddy Current Test

    4. Mechanical Tests includes Tension Test, Flattening Test, Flaring Test, Hardness Test.

    5. Impact Test subject to Standard request.

    6. Grain Size Test and Intergranular Corrosion Test.

    7. Visual Test and Endoscope Test for Surface Quality Test

    Typical Manufacturing Specifications:

    ASTM A249


    ASTM A269


    ASTM A270

    EN10217-7

    EN10357


    Also individual customer specifications.
