2 Inch Sstainless steel metric tubing ,Bright Annealed Stainless Steel Tubing 06Cr19Ni10

ASTM A778 Specification

The ASTM A778 specification includes straight seam & spiral butt seam welded unannealed austenitic stainless steel tubular products. These are intended for low/moderate temperatures, and corrosive service where treatment is not necessary for corrosion resistance.

Pipe Grades:

304,304L, 304H, 316, 316L, 316H, 321, 321H, 317, 317L, 347, 347H, 309, 309S, 310, 310S.

Available Sizes:

Any size can be provided but this process is usually used sizes of NPS 8’’ and upper.

Eletric-Fushion-Welded Austenitic Chromium-Nickel Stainless Steel Pipe For High-Temperature Service and General Applications

This specification cover electric-fusion-welded austenitic chromium-nickel stainless steel pipe suitable for corrosive or high-temperature service, or both, or for general applications. The pipes come in five classes.

Class1:
Pipe is double welded by processes employing filler metal in all passes and are completely radiographed.

Class2:
Pipe is double welded by processes employing filler metal in all passes without radiography

Class3:
Pipe is single welded by processes employing filler metal in all passes and are completely radiographed.

Class4:
Same as Class 3 except that the weld pass exposed to the inside pipe surface may be made without the addition of filler metal.

Class5:
Pipe is double welded by processes employing filler metal in all passes and is spot radiographed.

Spezilla specialise in manufacturing high quality precision stainless steel tube and other corrosion resistant alloy tubes that are designed to industry and customer specifications. Our products are manufactured to the highest quality standards and are very competitively priced. Our mission is to provide customized, flawless, reliable, and affordable corrosion resistant steel tubes to the world.

Tube Type:            Welded, Welded & Drawn. Straight Length or Coils.

Tube Materials:      Austenitic:    304, 304L, 316L, 321, 316Ti, 317L, 904L, 254 SMO;

                                                   1.4301, 1.4307, 1.4401, 1.4404, 1.4541, 1.4571, 1.4539, 1.4547;

                              Duplex:         2205, 2507;  1.4462, 1.4410;

                              Ferritic:         409, 439, 441, 444; 1.4512, 1.4510, 1.4509, 1.4521;

                              Nickel Alloy:  800, 800H, 800HT, 825, C276; 1.4876, 1.4958, 1.4959, 2.4858, 2.4819;

                              Titanium:       Gr.1, Gr.2;

Tube Size:              O.D. 4.00 - 38.10MM, W.T. 0.30 - 3.0MM.

Tube Finish:           As Welded, Bright Annealed, Annealed & Pickled, Polished, Custom Cutting.

Tube Standards:    ASTM A249, A268, A269, A270, A688, A789, B338;

                               EN 10217-7 TC1 & TC2, EN 10296-2, EN10357 etc.

Applications:          Heat Exchangers, Food & Beverage, Heating Elements, Automative, Tube Manipulation etc.

Spezilla appreciates the opportunity to help you with your questions about our operations, our products, our services or any other aspect of our business. We understand the demands of placing orders and the need for fast quotes, so we guarantee a response in 24 hours or less.
