ASTM SA268 TP410 Ferritic Stainless Steel Seamless Tube

Ask Lasest Price
Brand Name :	SPEZILLA
Model Number :	SMLS
Certification :	ISO9001, TS16949, PED, AD2000
Price :	NEGOCIATION
Payment Terms :	T/T, L/C
Supply Ability :	100TONS/MONTH
Delivery Time :	Ex-Mill 15 - 30DAYS

Add to Cart

Product Details
Company Profile

ASTM SA268 TP410 Ferritic Stainless Steel Seamless Tube

SA268 TP410 TP410S Tube Ferritic Stainless Steel Seamless Tube

A268 TP410 is a typical martensitic chromium-alloy steel grade. It does not have the nickel content and owns the following characteristic:

-Harding by heat treatment
-High hardness with good ductility
-Good corrosion resistance capability
-Good wear corrosion resistance
-High cold-deformation property

Ferritic stainless steels are classified in the 400 series, usually with 10% to 30% chromium content, and are often chosen for their excellent corrosion resistance and elevated temperature oxidation resistance. With greater strength than carbon steels, ferritics provide an advantage in many applications where thinner materials and reduced weight are necessary, such as automotive emission control systems. They are nonhardenable by heat treating and are always magnetic.

Item Code:	TP410 TP410S
Tube OD.:	1/4'' - 2''
Wall:	0.028'' - 0.120''
Length:	20FT
Material:	405
Standard:	ASTM A268 ASME SA268
Finish:	Annealed & Pickled.
Type:	Seamless Cold Drawn
Certification:	ISO9001
Mill Test Certificate:	EN10204 3.1
Packing:	Sleeved, Wooden Boxed

Quality Assurance:

Spezilla's seamless bright annealed stainless steel tubes are produced acc. to the following process and inspection to assure our quality:

1. Chemical Composition Analysis Test With 100% PMI.

2. Solution Annealing / Bright Annealed.

3. 100% Hydrostatic Test and 100% Eddy Current Test

4. Mechanical Tests includes Tension Test, Flattening Test, Flaring Test, Hardness Test.

5. Impact Test subject to Standard request.

6. Grain Size Test and Intergranular Corrosion Test.

7. Visual Test and Endoscope Test for Surface Quality Test

ASTM A268

ASME SA268

Available Tube Product Forms:

Straight.

Coiled.

Typical Applications:

Used for parts requiring a combination of good strength and toughness, plus reasonable corrosion resistance. Typical applications are: Bolts, Bushings, Fasteners, Gas Turbine Parts, Mine Equipment, Pump Parts, Petrochemical Equipment, Steam Turbine Parts, Studs, Valve Parts etc.

Material magnetic in all conditions.

Applications

The typical applications of grade 409 stainless steels are listed below:

Automotive exhaust tubing
Catalytic converter systems
Mufflers

SA268 TP410 TP410S Tube Ferritic Stainless Steel Seamless Tube

5% Test Solution at 120°F (49°C)	Corrosion Rate in Mils per Year and Millimeters per Year (mm/a)
5% Test Solution at 120°F (49°C)	Alloy 409	Alloy 410S	Alloy 420	Alloy 425 Mod	Alloy 440A	Alloy 430
Acetic Acid	0.88 (0.022)	0.079 (0.002)	1.11 (0.028)	4.79 (0.122)	2.31 (0.0586)	0.025 (0.0006)
Phosphoric Acid	0.59 (0.002)	0.062 (0.002)	0.068 (0.002)	0.593 (0.015)	0.350 (0.009)	0.029 (0.001)

ASTM A268 Tp410 tube composition:

Grade:	TP405	TP410	TP249	TP430	TP443	TP446-1	TP446-2	…	TP409
UNS	S40500	S41000	S42900	S43000	S44300	S44600	S44600	S40800	S40900
C, max	0.08	0.15	0.12	0.12	0.20	0.20	0.12	0.08	0.08
Mn,max	1.00	1.00	1.00	1.00	1.00	1.50	1.50	1.00	1.00
P, max	0.04	0.04	0.04	0.04	0.04	0.04	0.04	0.045	0.045
S, max	0.03	0.03	0.03	0.03	0.03	0.03	0.03	0.045	0.045
Si, max	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00	1.00
Ni	0.50max	…	…	…	0.75max	0.75max	0.50max	0.80max	0.50max
Cr	11.5-14.5	11.5-13.5	14.0-16.0	16.0-18.0	18.0-23.0	23.0-27.0	23.0-27.0	11.5-13.0	10.5-11.7
Mo	…	…	…	…	…	…	…	…	…
Al	0.10-0.30	…	…	…	…	…	…	…	…
Cu	…	…	…	…	0.90-1.25	…	…	…	…
N	…	…	…	…	…	0.25	0.25	12xCmin	6xCmin
Ti	…	…	…	…	…	…	…	1.10max	0.75max

Chemical Composition
	Min. %	Max %
Carbon	0.09	0.15
Silicon	0	1.00
Manganese	0	1.00
*Nickel	0	1.00
Chromium	11.50	13.50
Phosphorous	0	0.04
Sulphur	0	0.03
*Nickel additional option
